Features
● Adopt adjustable UHF frequency, stable performance, reliable transmission.
● Integrated antenna distribution system, reduce antenna mutual radiation interference effectively.
● TFT color display to show functions.
● Half-U standard housing design.
● Max transmission power: 13dBm (depends on the regions)
● 50Hz-18KHz flat frequency response.
Receiver
● Receiving channel：1CH/2CH/4CH
● Carrier wave：498-510MHz, depends on the regions
● Oscillation：PLL phase-locked frequency synthesis
● Frequency sensitivity：Input 6dBμV, S/N>80dB
● Operating distance：60 meter
(Note: the actual range depends on RF signal absorption, reflection and interference factors)
● T.H.D.：<0.5% @ 1KHz
● Transmission bandwidth：< 100KHz
Handheld transmitter
● Oscillation mode：PLL phase-locked frequency synthesis
● RF carrier ware range：498-510MHz depends on regions
● Pickup gain：Fixed gain
● Transmission power：13dB
● Current drain：standard＜130mA
● Display：LCD
● Cartridge mode：Dynamic cardioid cartridge
Bodypack transmitter
● Oscillation mode：PLL phase-locked frequency synthesis
● RF carrier ware range：498-510MHz depends on regions
● Pickup gain：Adjustable gain
● Transmission power：13dB
● Current drain：standard＜130mA
● Display：LCD
● Cartridge mode：Condenser cardioid cartridge
