System
|
Built-in Crossover two way
full ranger active speaker
|
| Cabinet material |
|
| Cabinet Colors |
Black |
|
Driver quantity
|
12{18;X1(Bass)
1XØ44mm Driver
|
| Tweeter Dispersion (HxV): |
90°x60° |
|
Frequency (-3dB)
|
48Hz~18KHz
|
|
Frequency (-10dB)
|
35Hz~20KHz
|
| Average Sound Level (dB/1M) |
122dB |
|
PEAK Sound Level (dB/1M)
|
128dB
|
| Level Adjust |
± 12dB (5KHz) -Treb
|
|
± 12dB (100KHz) -Bass
|
| Output Power |
400W (Bass) + 100W (Treb) |
|
Distortion
|
Line-0.02%, Microphone-0.04%
|
| Load Impedance |
|
| Input Impedance |
Line - 47KOhm, Microphone - 10KOhm |
|
Connector type
|
|
|
Power supply
|
|
|
Dimension(WXDXHmm/Pcs)
|
430X310X570mm
|
|
Packaging Dimension(WXDXHmm/Pcs)
|
|
|
Net weight(kg/Pcs)
|
21kg
|
|
Gross weight(Kg/Pcs)
|
24kg
|
